How do Carbon Fiber Structural Repairs Work?

Sep 16, 2022
3 min read

Updated: 4 days ago

Carbon fiber structural repair uses carbon fiber-reinforced polymer (CFRP) bonded to an existing structural member to add reinforcement where additional strength, confinement, or load capacity is needed. Because CFRP is lightweight, corrosion-resistant, and installed externally, it can strengthen concrete, masonry, and other structural elements without adding significant section size or dead load.

How Does Carbon Fiber Structural Repair Work?

A CFRP strengthening system works by transferring structural demand from the existing substrate into high-strength carbon fibers through a bonded epoxy matrix. The fiber orientation is selected to match the required load path. Unidirectional fibers carry force primarily in one direction, while bidirectional fabrics provide reinforcement in two directions.

For a comparison of the two fabric types, see Unidirectional vs. Bidirectional Carbon Fiber.

Typical CFRP Repair Process

1. Evaluate the existing structure. The cause of cracking, deterioration, movement, or inadequate capacity should be identified before strengthening begins. Existing geometry, reinforcement, loads, substrate condition, and environmental exposure all affect the repair design.

2. Repair deterioration and cracks. Unsound concrete, corrosion-related damage, voids, or structural cracks are repaired as required before the CFRP system is installed. Epoxy injection, repair paste, corrosion treatment, or other project-specific materials may be part of this stage.

3. Prepare the substrate. The surface must be sound, clean, and profiled for bonding. Coatings, laitance, weak concrete, dust, and contaminants are removed so the epoxy can develop a reliable bond to the structure.

4. Install the carbon fiber system. Structural epoxy is applied and the specified carbon fiber fabric is saturated and positioned in the engineered direction. Multiple layers, overlaps, wraps, or anchorage details may be required depending on the repair objective.

5. Protect and finish the installation. Where required by the environment or project specification, the completed CFRP system may receive a protective coating or finish for UV, fire, abrasion, marine, or architectural exposure.

Where Is Carbon Fiber Strengthening Used?

CFRP systems can be used for flexural strengthening, shear reinforcement, confinement, crack stabilization, load-capacity upgrades, seismic strengthening, and repair of deteriorated structural members. Common applications include beams, columns, slabs, foundation walls, retaining walls, bridges, parking structures, marine infrastructure, and timber piles.

Explore the SRS Applications library for application-specific repair examples and strengthening methods.

What Carbon Fiber Products Are Used?

SRS-600UNI is a 600 gsm unidirectional carbon fiber fabric used where reinforcement is primarily required in one direction.

SRS-660BI is a 660 gsm bidirectional carbon fiber fabric used where reinforcement is needed in two directions, including confinement, shear, and localized strengthening applications.

SRS-1000 Structural Epoxy Resin is used to bond and saturate SRS carbon fiber fabrics in wet-layup CFRP systems.

Does Every Carbon Fiber Repair Need Engineering?

The required engineering depends on the structure, repair objective, loading, jurisdiction, and project scope. Structural strengthening should be based on the actual member condition and load path rather than a generic fabric layout. SRS can review project photographs, dimensions, drawings, and available structural information to help identify the appropriate materials, quantities, repair approach, and engineering support.

Submit a project for review for project-specific guidance.

Download the Carbon Fiber Structural Repair Guide

SRS also provides a three-page brochure that explains carbon fiber structural repairs and answers common client questions. The complete guide is available below.
